45KH14N14V2M (45Х14Н14В2М)

UNS S66009

SUH31

Diameter 2 - 75 mm

Технология плавки：IF/EAF/LF/AOD/VOD/VIM/ESR/VAR

Контроль качества: Тестирование компонентов, испытание механических свойств,Ультразвуковой контроль внутренней стороны,Вихретоковое тестирование поверхности...

45KH14N14V2M ( 45Х14Н14В2М ) is high alloy high-temperature steel

Equivalent grade

USA

Japan

France

England

Hungary

Poland

Czechia

JIS

AFNOR

MSZ

CSN

S66009

SUH31

Z35CNWS14-14

331S42

SZ8

4H14N14W2M

17322

Chemical composition

C	Si	Mn	Ni	S	P	Cr	Mo	W
0.4 - 0.5	max 0.8	max 0.7	13 - 15	max 0.02	max 0.035	13 - 15	0.25 - 0.4	2 - 2.8

Mechanical properties under Т=20oС for grade

Assortment	Dimension	Direct.	sв	sT	d5	y	KCU	Heat treatment
-	mm	-	MPa	MPa	%	%	kJ / m2	-
Bar, GOST 5949-75			710	315	20	35		Drawing 810 - 830oC, air,

Brinell hardness for 45KH14N14V2M ( 45Х14Н14В2М ) (annealing) , Bar GOST 5949-75

HB 10 -1 = 197 - 285 MPa

Weldability :

without limitations- welding is done without heating and subsequent heat treeting

limited weldability- welding is possible under heating up to 100-120 grade and subsequent heat treeting

hard weldability- obtaining the quality welding needs the additional operations:heating up to 200-300 grade; the heat treeting ia annealing

Physical properties

T	E 10- 5	a 10 6	l	r	C	R 10 9
Grade	MPa	1/Grade	Watt/(m·Grade)	kg/m3	J/(kg·Grade)	Ohm·m
20	2.08		14	8000		815
100	1.96		16			875
200	1.9	17	17	7930		945
300	1.81		19		507	1000
400	1.73	18	20	7840	511	1055
500	1.66		21		523	1098
600	1.57	18	22	7760	528	1142
700	1.49		24			1172
800	1.41	19		7660
T	E 10- 5	a 10 6	l	r	C	R 10 9
