NIMONIC® ALLOY 80A


NIMONIC® ALLOY 80A

UNS N07080,W-Nr.2.4952

Diameter: 2 - 75 mm

Supply Condition: Hot rolled; Annealed; Solution; Solution&Aged; Hardened&Tempered

Smelting Technology:IF/EAF/LF/AOD/VOD/VIM/ESR/VAR

Quality Control: Component testing, mechanical properties testing,Ultrasonic testing for inner side,Eddy current testing for surface...

Nimonic® alloy 80A is a wrought, age-hardenable nickel-chromium alloy. Alloy 80A is similar to alloy 75 but made precipitation hardenable by additions of aluminium and titanium. Alloy 80A has good corrosion and oxidation resistance and high tensile and creep-rupture properties at temperatures to 815ºC (1500ºF). Vacuum refined versions are also available. Alloy 80A is used for gas-turbine components (blades, rings, discs), bolts, tube supports in nuclear generators, exhaust valves in internal combustion engines and has many other offshore/marine, automotive and electrical applications.

Chemical Composition

Grade C Si Mn S Cr Ni Cu Co Ti Al Fe Others
80A ≤0.1 ≤1.0 ≤1.0 ≤0.015 18.0-21.0 balance ≤0.2 ≤2.0 1.8-2.7 1.0-1.8 ≤3.0 B:≤0.008, Zr:≤0.15
